Description

blank

Dimensions and Weight:

Dimensions:400mm(L)*230mm(W)*185mm(H)
Net Weight: 3.8kg


Printing Technology:

Print Method:
Impact dot matrix

Print Direction:
Bi-direction with logic seeking

Color:
Black

Number of Pins in Head:
24 pins

Emulation Command:
EPSON ESC/P: OKI emulation

Print Speed:

Ultra-High Speed Draft:
10 cpi:300 cps;15 cpi: 450 cps

High Speed draft:
10 cpi: 225 cps ;15 cpi: 338cps



Reliability:

Printhead Life:
500 million strokes / wire

Mean Time Between Failure (MTBF):
≥12,000 hours




Print Characteristics:

ASCII character:
96

International character:
16 countries

IBM character:
32

Chinese:
GB18030 24*24 Bitmap Font(21887)

Environmental Conditions (Operating):

Temperature:
+5 – 40°C

Humidty:
10 – 80 % RH

Power supply:
+35V(1.2A)C

Power Consumption
(Sleep Mode):

Approx. 0.5W

Paper Path:

Push Insertion:
Front in, front out

Pull Tractor:
Rear in, front out


Paper Media:

Cut Sheet
(Single Sheet):

Length:
64.0 – 364.0mm (2.5 – 14.3″)

Width:
64.0 – 297.0mm (2.5 – 11.3″)

Thickness:
0.07 – 0.18mm

Cut Sheet
(Multi-part Forms):

Length:
64.0 – 364.0mm (2.5 – 14.3″)

Width:
64.0 – 297.0mm (3.0 – 10.5″)

Thickness:
0.07 – 1.2 mm

Continuous Paper
(Single Sheet / Multi-part):

Length:
≥ 139.7 mm (≥5.5″)

Width:
76.2 – 266.7mm (3 – 10.5″)

Thickness:
0.07- 1.2 mm (0.0027 – 0.0047″)

Copy:
1 original + 6 copies


Consumables:

Ribbon Cartridge (Black):
STAR-NX500/BP650ribbon

Ribbon Cartridge:

Standard:
Fabric Ribbon Cartridge (Black)

Ribbon Life:
Approx. 5 million characters


Acoustic Noise:

Approx. 65 dB(A)
(ISO 7779 pattern)

Input Data Buffer:

128 KB

Interface:

USB 2.0


PR-855 driver(20221214)

Download the Drive

PR-855 User Guide(202305)

Download the User Guide
